The component of product: feeder system, response system, control system, security system, residual liquid automatic processing system

Reaction principle: NaCLO3 + 2 HCL - CLO2 + 1/2 cl2 + NaCL + H2O

Use of the material:

Sodium chlorate industry firsts: (GB/T1618-2008, content of 99% or higher);

Acid salt (GB320-2006 industry firsts, concentration of 31% or higher)

Performance characteristics:

Mixer production of chlorine dioxide is given priority to, the compound disinfectant chlorine is complementary, according to the content of active chlorine gauge CLO2 is greater than 85%.

Mixer reactor is made of high quality high temperature resistant, corrosion resistant composite material, equipment service life is long.

Reaction temperature 50 ℃, raw material conversion rate 90% or higher.

Raw material conveying imported metering pump, stable running, accurate measurement.

Mixer control system by microcomputer touch key operation. With automatic temperature closed loop control, overtemperature under-voltage stop safety control functions such as automatic alarm, can timely show the parameters such as reaction temperature.

Mixer equipment automatic control operation, increase the corresponding control components, but with constant pressure water supply system to realize linkage operation.

Reserved RS485 interface, which can realize the residual chlorine, flow and equipment working status output and remote control.
